This product has been discontinued.

The manufacturer has discontinued this product permanently. Please see the alternative product below.

100k BTU 80% AFUE Multi Speed Goodman Gas Furnace - Downflow - 21" Cabinet

Item: HA10606
Model: GDS81005CN
Condition: New

100k BTU 80% AFUE Multi Speed Goodman Gas Furnace - Downflow - 21" Cabinet Zoom

Photo Gallery

The Goodman GDS8 Series Energy-Efficient Multi-Speed Gas Furnace is full of hot air! Which is good, since it's a gas furnace and blowing hot air is the whole point. Equipped with superior Goodman components like a heavy-duty heat exchanger and multi-speed blower motor, if you're in the market for a new gas furnace, a Goodman GDS8 might be exactly what you need. It even comes with a lifetime warranty for that awesome heat exchanger.

Get everything right and save time

Contact an expert now.

Call: 1-270-575-9595

or click here to chat

Goodman

What's Included

What customers are saying...



Overview

The Goodman GDS8 Series Energy-Efficient Multi-Speed Gas Furnace is full of hot air! Which is good, since it's a gas furnace and blowing hot air is the whole point. Equipped with superior Goodman components like a heavy-duty heat exchanger and multi-speed blower motor, if you're in the market for a new gas furnace, a Goodman GDS8 might be exactly what you need. It even comes with a lifetime warranty for that awesome heat exchanger.

Don’t wait until the dead of winter to replace your furnace! We understand that you want to make an economical and reliable choice when picking a replacement. But what should you look for?

You will need to know the efficiency number from your old furnace and cost of your recent fuel bills to determine how much you can save with a new unit. After determining the details, you can calculate the potential savings when upgrading to a new furnace and when you will see your costs break in your favor. Keep in mind that the higher the AFUE, the mostly costly the unit will be upfront.

Th GDS81 furnace from Goodman is a great choice if you are looking to keep pricing low on the frontend and still save monthly when upgrading from an older model. But the efficiency is not always the deciding factor or most important part when purchasing a new heater. You will want to make sure your home can support the size of this cabinet. This particular furnace is 21” and operates in downflow. This means that it is reasonably sized and can be placed in an attic or other elevated space.

100k BTU 80% AFUE Multi Speed Goodman Gas Furnace - Downflow - 21" Cabinet wards off damage with its durable cabinet made from aluminum steel. As an added bonus to you, the heat exchanger section is lined with insulation so you don’t lose unnecessary heat, making this a cabinet rated for less than 2% air leakage!

Goodman HA10606

Manufacturer Highlights

The Goodman® brand GDS Gas Furnaces offer energy efficiencies and operating sound levels that are among the best in the heating and cooling industry. Quality manufacturing as well as easy installation and maintenance make this unit one of the best values on the market.

Standard Features

  • Heavy-duty aluminized-steel, dual diameter tubular heat exchanger
  • Single-stage gas valve
  • Durable Hot-surface igniter
  • Quiet, single-speed draft induced
  • Self-diagnostic control board
  • Color-coded low-voltage terminals
  • Multi-speed blower motor
  • California Low NOx emissions models available
  • Convenient left or right connection for gas and electrical service
  • Heavy-gauge steel cabinet with durable baked-enamel finish
  • Foil faced insulated heat exchanger

Cabinet Features

  • Convenient left or right connection for gas and electrical service
  • Heavy-gauge steel cabinet with durable baked-enamel finish
  • Foil faced insulated heat exchanger

Warranty Terms

For a full description of all warranties applicable to this product as well as individual manufacturer requirements, please review the manufacturer's consumer brochure and/or product warranty documents.  Online warranty registration must be completed within 60 days of installation.  Due to state laws, online registration is not required in California or Quebec. Call for warranty availability on scratch & dent and surplus items.

For additional warranty information, click here.

Specifications

Model GDS81005CN
UPC 663051518162
AHRI Number 5012582
Gas Furnace Efficiency 80%
Air Flow Direction Downflow
Configuration Floor Mounted
Avg Coverage Area 1,750 - 2,100 Sq Ft
Blower Motor Multi Speed
Cooling Compatibility (up to) 5 Ton
Electrical Phase 1-Phase
Exhaust Pipe Metal
Fuel Source Natural Gas
Gas Valve Single Stage
Max Overcurrent Protection 15 amps
Primary Heating Capacity 95,001 - 100,000 BTU
Product Height (in) 33.375
Product Length (in) 28
Product Width (in) 21
System Application Type Central Split Systems
Vent Connection 6 inches
Voltage 120
Warranty 10 Year Parts, Lifetime Heat Exchanger
Weight (lbs) 175.0000
