24k BTU 16.5 SEER2 MrCool DIY Select Ductless Heat Pump Split System - with 11.5ft Line Set & 1 Year Labor Warranty
MRCOOL

Accessories
Description / Documents
Does one room of your home struggle to stay comfortable in extreme outdoor temperatures? Looking for a solution to add heating and cooling to your shed, garage, or workshop without the need for ductwork? With a 24k BTU 16.5 SEER2 MrCool DIY Select Ductless Heat Pump Split System - with 11.5ft Line Set & 1 Year Labor Warranty, you can ensure the exact conditions you want in a single zone all year long. Gaining the support of ETL listing, as well as both Energy Star and AHRI certifications, the MrCool DIY Select Heat Pump showcases the validity of every safety, functional, and efficiency claim by passing inspections from third-party agencies. Make the most of every inch of your living space with the addition of a 24k BTU MrCool Ductless Split System.
Built to go the distance for your needs, the condenser in the 24k BTU 16.5 SEER2 MrCool DIY Select Ductless Heat Pump Split System - with 11.5ft Line Set & 1 Year Labor Warranty has everything you need and more to stay comfortable. The use of inverter technology stops the temperature in your home from fluctuating too far from your chosen set-point, optimizing your comfort while reducing energy usage. Thanks to the pre-charged 11.5-foot line set, you won’t need a professional to vacuum refrigerant through the system during setup. With this difficult step removed, and every other step outlined in detail in the installation manual, the MrCool DIY Select Heat Pump makes it easy to handle do-it-yourself setup at any skill level.
Designed with your comfort in mind, the air handler in the 24k BTU 16.5 SEER2 MrCool DIY Select Ductless Heat Pump Split System - with 11.5ft Line Set & 1 Year Labor Warranty puts climate control well within your reach. The remote control makes adjusting the temperature within the room a breeze, while the smartphone app extends this ability to monitor and change your settings to anywhere with a cell signal. With the ability to switch modes, set timers, and more while you’re out and about, the MrCool Air Handler makes it simple to save money without compromising your comfort when you’re home. When you want more than just temperature regulation from your climate control system, the MrCool DIY Select Split System is exactly what you’ve been searching for.
Between the powerful performance you crave, 1 year of labor warranty, and the limited warranty that covers 1 year on parts and 2 years on the compressor by default, what more could you be looking for? Acquire a 24k BTU MrCool DIY Select Ductless Heat Pump Split System with 11.5ft Line Set equipped with R454B refrigerant today to ensure your family can craft a comfortable indoor ambiance any time of the year.
From the Manufacturer
Customer Reviews / Q&A
Specifications
System Overview
| Model | DIYS-24-HP-230A11-O |
|---|---|
| UPC | 840433619536 |
| AHRI Number | 218004487 |
| Configuration | Wall Mounted |
| Bundle Avg Coverage Area | 1,000 - 1,200 Sq Ft |
| Bundle Cooling Capacity | 2 Ton |
| Bundle Cooling Efficiency (SEER2) | 16.5 |
| Heat Pump Efficiency (HSPF2) | 8.3 |
| Series | DIY |
| Zones | 1 |
| Region Compatibility | Nationwide |
DIYS-24-HP-C-230A11-O Specifications:
| Model | DIYS-24-HP-C-230A11-O |
|---|---|
| UPC | 840255595681 |
| AHRI Number | 218004487 |
| Product Height (in) | 26.5 |
| Avg Coverage Area | 1,000 - 1,200 Sq Ft |
| Product Length (in) | 13.46 |
| Compressor | Inverter |
| Product Width (in) | 35.04 |
| Cooling Capacity | 2 Ton |
| Electrical Phase | 1-Phase |
| Heat Pump Efficiency (HSPF2) | 8.3 |
| Line Set Connection Type | Quick Connect |
| Liquid Line Size | 3/8 inch |
| Max Overcurrent Protection | 20 amps |
| Weight (lbs) | 96.900000 |
| Primary Heating Capacity | 20,001 - 25,000 BTU |
| Refrigerant | R-454b |
| Cooling Efficiency (SEER2) | 16.5 |
| Series | DIY |
| System Application Type | Ductless Split Systems |
| Voltage | 240 |
| Warranty | 1 Year Parts, 2 Year Compressor |
| Region Compatibility | Nationwide |
DIYS-24-HP-WMAH-230A13-O Specifications:
| Model | DIYS-24-HP-WMAH-230A13-O |
|---|---|
| UPC | 840255595643 |
| Product Height (in) | 13.27 |
| Configuration | Wall Mounted |
| Product Length (in) | 9.21 |
| Air Flow Direction | Horizontal |
| Product Width (in) | 42.6 |
| Blower Motor | Multi Speed |
| Cooling Capacity | 2 Ton |
| Electrical Phase | 1-Phase |
| Line Set Connection Type | Quick Connect |
| Liquid Line Size | 3/8 inch |
| Max Overcurrent Protection | 15 amps |
| Weight (lbs) | 35.490000 |
| Refrigerant | R-454b |
| Series | DIY |
| Special Features | WiFi Capable |
| Suction Line Size | 5/8 inch |
| System Application Type | Ductless Split Systems |
| Voltage | 240 |
| Warranty | 1 Year Parts, 2 Year Compressor |
DIYS-24-HP-B-WMAH-230A13-O Specifications:
| Model | DIYS-24-HP-B-WMAH-230A13-O |
|---|---|
| UPC | 840433619949 |
| Product Height (in) | 13.27 |
| Configuration | Wall Mounted |
| Product Length (in) | 9.21 |
| Air Flow Direction | Horizontal |
| Product Width (in) | 42.6 |
| Blower Motor | Multi Speed |
| Cooling Capacity | 2 Ton |
| Electrical Phase | 1-Phase |
| Line Set Connection Type | Quick Connect |
| Liquid Line Size | 3/8 inch |
| Max Overcurrent Protection | 15 amps |
| Weight (lbs) | 35.490000 |
| Refrigerant | R-454b |
| Series | DIY |
| Special Features | WiFi Capable |
| Suction Line Size | 5/8 inch |
| System Application Type | Ductless Split Systems |
| Voltage | 240 |
| Warranty | 1 Year Parts, 2 Year Compressor |
DMS1Y4+000125 Specifications:
| Weight (lbs) | 0.000000 |
|---|---|
| Model | DMS1Y4+000125 |
