Overview
The 5 Ton MrCool Evaporator Coil is designed for large vertical furnaces or air handlers. It sits vertically and its slim 24.5 inch cabinet can easily fit in a variety of spaces.
This unit works to keep energy consumption low while reducing your monthly energy bill.
The interlocking door assemblies and snug seal line decrease the chances of air leakage. With this feature, your evaporator coil can collaborate with your compatible condenser to perform at top levels and drive more air from your unit into your home without air escaping.
Another impressive feature of this unit is the MrCool drain pan. The drain pan keeps water buildup to a minimum and catches condensation from the coils. This reduces the chance of corrosion and damage to the unit and the floor of the space the unit is placed on. The drain pan also features antimicrobial properties to make sure that bacteria does not accumulate and damage your unit or spread into your air.
In the occasion of maintenance or service, it's never been easier to access your evaporator coil. This tubing of this unit is conveniently located at the door split and foil-facing insulation. Plus, it has an external mounted cabinet distributor body so you can change orifice sizes and TXV connections without any trouble. If the issue is bigger than a simple fix, MrCool backed this unit with a lengthy limited parts warranty which can be accessed upon purchase of your unit. Just another reason to choose an evaporator coil and cabinet from MrCool!

Manufacturer Highlights
This is a brand new 5 ton, R410A & R22 refrigerant, Upflow cased Evaporator Coil. This efficient and durable coil is the solution for heat pumps and air conditioners for fast, flexible application. This Signature Series coil, when appropriately paired with a MRCOOL Signature Series condenser and gas furnace or modular blower, can achieve efficiency ratings of up to 16 SEER.
Standard Features
- Interlocking door assemblies and snug line sealgrommets to minimize air leakage
- All units UL Listed and AHRI Certified
- R22 & R410A compatible
- Microban® antimicrobial additive in the drain pan to resist mold and mildew growth
- Foil-face insulation for easy cleaning
- All drain pans are compatible with UV lights
- Mobile home approved
- Superior service access to components, withtubing located at door split and foil-face insulation
- 10-Year Parts Limited Warranty
Warranty Terms
For a full description of all warranties applicable to this product as well as individual manufacturer requirements, please review the manufacturer's consumer brochure and/or product warranty documents. Online warranty registration must be completed within 60 days of installation. Due to state laws, online registration is not required in California or Quebec. Call for warranty availability on scratch & dent and surplus items.
Installation of any product must comply with all applicable codes and regulations. The service of a certified and trained electrical technician may be required for the installation process.
Specifications
Model | MCVP60CNPA |
---|---|
Air Flow Direction | Upflow |
Cooling Capacity | 5 Ton |
Liquid Line Size | 3/8 inch |
Product Height (in) | 31.5 |
Product Length (in) | 22 |
Product Width (in) | 21 |
Refrigerant | R-410a |
Series | Signature |
Suction Line Size | 7/8 inch |
Weight (lbs) | 73.0000 |
California Residents | see Prop 65 WARNING |
