6 Ton Horizontal Ground Loop Geothermal Installation Kit

Models FUSE1600750600, HPVC1207X6S, GP22K-SU10F-R2, HK10U9012, 9992102

Customize 6 Ton Horizontal Ground Loop Geothermal Installation Kit

* Required Fields

In stock

Ships Within 1-2 Business Days

    Get $100 Cash Back on Your Qualifying Purchase

    1. Spend over $1000 on heating and air equipment.
    2. Share this video publicly on your existing Facebook news feed. https://youtu.be/O4nmrlbF0aA
    3. Email a screenshot of the video on your facebook profile to [email protected] along with your order number.
    4. Get a check mailed to you for $100.

    Limited Time Offer. Act Now!

    Rebate only valid for qualifying purchases made after September 19, 2022 until further notice. Rebate claim limited to one per customer. Purchase must be made prior to sharing video. Please allow 1-2 weeks for processing. May not be used in conjunction with any other offer or discount. Video privacy setting must be public.

    Get everything right and save time

    Contact an expert now.

    This Bundle Includes

    3/4" x 600' CenFuse High Density Polyethylene Loop Pipe - SDR 11
    Item: HA12127 Model: FUSE1600750600
    Qty: 6
    1 1/4" x 3/4" 6 Circuit Insulated Header - Straight Pattern
    Item: HA12106 Model: HPVC1207X6S
    Qty: 1
    Geo-Pulse Non-Pressurized Geothermal Flow Center - Two Pump
    Item: HA12099 Model: GP22K-SU10F-R2
    Qty: 1
    Propylene Glycol Heat Transfer Fluid - 5 Gallon
    Item: HA12126 Model: 9992102
    Qty: 2

    What's included

    • Ingrams FUSE1600750600
    • Ingrams HPVC1207X6S
    • Ingrams GP22K-SU10F-R2
    • Ingrams HK10U9012
    • Ingrams 9992102
    • Owner Manual
    • Lifetime Tech Support

    Do you need a geothermal installation kit for a 6 ton horizontal ground loop geothermal heat pump? Well, you're in luck, since this installation kit is for exactly that! This IWAE-only custom ground-source bundle comes with just about everything you need for a typical 6 ton geothermal heat pump installation.

    This ground-source geothermal installation kit comes with 3600 feet of ¾" CenFuse high density polyethylene loop piping. It has a ¼" x ¾" 6 circuit insulated header in a straight pattern. There is a two-pump Geo-Pulse Non-Pressurized Flow Center, and 12 ft of 1" hose kit with 1" male pipe thread to barb 90 degree elbow fittings. Finally, we added 10 gallons of ProTek PG Plus propylene glycol heat transfer fluid.

    What doesn't this kit include? It doesn't include the geothermal heat pump itself. You will, of course, need one of those for a successful installation. You might also need one or two other components depending on your installation. Should you find yourself in such a need, give us a call. We can always custom order parts and components for our customers and put together a special geothermal installation kit if this doesn't fit your needs exactly.

    As always, you receive technical and product support for the life of the system.

    Warranty Terms

    For a full description of all warranties applicable to this product as well as individual manufacturer requirements, please review the manufacturer's consumer brochure and/or product warranty documents.  Online warranty registration must be completed within 60 days of installation.  Due to state laws, online registration is not required in California or Quebec. Call for warranty availability on scratch & dent and surplus items.

    For additional warranty information, click here.

    More Information
    Model GEOKIT-6H
    California Residents see Prop 65 WARNING

    FUSE1600750600 Specifications:

    More Information
    Model FUSE1600750600
    Material Polyethylene
    Weight (lbs) 74.000000
    Pipe Diameter 3/4 inch
    Warranty 50 Year

    HPVC1207X6S Specifications:

    More Information
    Model HPVC1207X6S
    Product Height (in) 2
    Header Size 1 1/4 inch
    Product Length (in) 12
    Manifold Size 3/4 inch
    Product Width (in) 26
    Material PVC
    Weight (lbs) 5.000000
    Zones 6

    GP22K-SU10F-R2 Specifications:

    More Information
    Model GP22K-SU10F-R2
    Product Height (in) 34
    Electrical Phase 1-Phase
    Product Length (in) 8
    Product Width (in) 15
    Weight (lbs) 98.000000
    Pumps 2
    Voltage 240
    Warranty 5 Year
    Zones 1

    HK10U9012 Specifications:

    More Information
    Model HK10U9012
    Weight (lbs) 1.000000
    Pipe Diameter 1 inch

    9992102 Specifications:

    More Information
    Model 9992102
    Product Height (in) 15
    Product Length (in) 12
    Product Width (in) 12
    Weight (lbs) 41.710000
