36k BTU 22.5 SEER MrCool Olympus Ductless Heat Pump Split System - 2 Zone Concealed Duct - 18k+18k

Item: HA11754
Models: MULTI4-36HP230V1, DUCT-18HP-230
Condition: New

36k BTU 22.5 SEER MrCool Olympus Ductless Heat Pump Split System - 2 Zone Concealed Duct - 18k+18k Zoom

Photo Gallery

Two zone individualized comfort comes your way with this 36k BTU 22.5 SEER MRCOOl Olympus Ductless Heat Pump Split System. The MULTI4-36HP230V1 condenser is built with self-diagnostic features like leak detection to protect the compressor from a low coolant event. Two 18k concealed duct units govern individualized zones up to 750 sq ft. So you can be warm in the master suite while the family cools it in the den.

Availability: In stock

$3,622.00 Click for price

Price as configured:

$3,622.00 Click for price
Ingram Financing


Ships Within 1-2 Business Days

Get everything right and save time

Contact an expert now.

Call: 1-800-360-1569

or click here to chat

This Bundle Includes

36k BTU MrCool Olympus Ductless Heat Pump Condenser - 4 Zone 36k BTU MrCool Olympus Ductless Heat Pump Condenser - 4 Zone Item: HA11047 Model: MULTI4-36HP230V1 Qty: 1
18k BTU MrCool Olympus Ceiling Recessed Air Handler 18k BTU MrCool Olympus Ceiling Recessed Air Handler Item: HA11058 Model: DUCT-18HP-230 Qty: 2

* Required Fields

MrCool

What's Included

What customers are saying...

Overview

Product Features

Two zone individualized comfort comes your way with this 36k BTU 22.5 SEER MRCOOl Olympus Ductless Heat Pump Split System. The MULTI4-36HP230V1 condenser is built with self-diagnostic features like leak detection to protect the compressor from a low coolant event. Two 18k concealed duct units govern individualized zones up to 750 sq ft. So you can be warm in the master suite while the family cools it in the den.

Warranty Terms

For a full description of all warranties applicable to this product as well as individual manufacturer requirements, please review the manufacturer's consumer brochure and/or product warranty documents.  Online warranty registration must be completed within 60 days of installation.  Due to state laws, online registration is not required in California or Quebec. Call for warranty availability on scratch & dent and surplus items.

For additional warranty information, click here.

Specifications

Product Specifications

Model MULTI4-36HP230V1,DUCT-18HP-230,DUCT-18HP-230
UPC 856536005855
AHRI Number 8977709
Avg Coverage Area 1,500 - 1,800 Sq Ft
Cooling Capacity 3 Ton
Cooling Efficiency 19 SEER and Above
EER 11.5
Heat Pump Efficiency (HSPF) 10.2
Series Olympus
Zones 2
Region Compatibility Nationwide
Popular Applications Apartment, Duplex, Hotel Room, Office, Single Family Home

Individual Item Specifications

MULTI4-36HP230V1 Specifications:

Model MULTI4-36HP230V1
UPC 856536005855
Avg Coverage Area 1,500 - 1,800 Sq Ft
Compressor Inverter
Cooling Capacity 3 Ton
Electrical Phase 1-Phase
Heat Pump Efficiency (HSPF) 10.2
Lineset Connection Type Flared
Liquid Line Size 1/4 inch
Max Overcurrent Protection 45 amps
Primary Heating Capacity 35,001 - 40,000 BTU
Product Height 32
Product Length 16
Product Width 37
Cooling Efficiency 19 SEER and Above
Series Olympus
System Application Type Ductless Split Systems
Voltage 240
Warranty 5 Year Parts, 7 Year Compressor
Weight 157.0000
Region Compatibility Nationwide

DUCT-18HP-230 Specifications:

Model DUCT-18HP-230
UPC 853962006531
Air Flow Direction Horizontal
Configuration Ceiling Mounted
Blower Motor Variable Speed
Cooling Capacity 1.5 Ton
Electrical Phase 1-Phase
Heat Strip Compatibility NA
Lineset Connection Type Flared
Liquid Line Size 1/4 inch
Max Overcurrent Protection 15 amps
Product Height 8
Product Length 25
Product Width 36
Series Olympus
Suction Line Size 1/2 inch
System Application Type Ductless Split Systems
Voltage 240
Warranty 5 Year Parts
Weight 51.0000
