48k BTU 22.4 SEER MrCool Olympus Ductless Heat Pump Split System - 4 Zone Concealed Duct - 12k+12k+12k+18k

Item: HA11806
Models: MULTI5-48HP230V1, DUCT-12HP-230, DUCT-18HP-230
Condition: New

48k BTU 22.4 SEER MrCool Olympus Ductless Heat Pump Split System - 4 Zone Concealed Duct - 12k+12k+12k+18k Zoom

Photo Gallery

Related Videos

Get rid of all the problems of a ducted system, and rely on the flexibility and efficiency of a MRCOOL Olympus. This quad-zone ductless heat pump split system can cover larger spaces with an 18k concealed duct-style air handler and three 12k concealed duct air handlers. The system is anchored by a MULTI5-48HP230V1 condenser with 54k BTU capacity and rated a 22.4 SEER.

Availability: Out of stock

As low as: $6,906.00

Price as configured: $6,906.00

Call for availability

$100 Rebate Offer

Get everything right and save time

Contact an expert now.

Call: 1-270-575-9595

or click here to chat

This Bundle Includes

12k BTU MrCool Olympus Ceiling Recessed Air Handler 12k BTU MrCool Olympus Ceiling Recessed Air Handler Item: HA11057 Model: DUCT-12HP-230 Qty: 3
18k BTU MrCool Olympus Ceiling Recessed Air Handler 18k BTU MrCool Olympus Ceiling Recessed Air Handler Item: HA11058 Model: DUCT-18HP-230 Qty: 1

Overview

MRCOOL has a series for every consumer! The tech buff can appreciate MRCOOL products as they come equipped with wireless capabilities to control your system from your smartphone. The small business owner can take advantage of ductless technology with a system that introduces fresh air like this one. The concealed duct system will suspend from your ceiling space and provide you with comfort without the need for combustible gases. MRCOOL products come with highly efficient components that will last you longer and save you money on your utility bills, compared to alternative HVAC brand. Because you do not need to install this system on your roof, you can avoid costly crane charges that are associated with rooftop units.

The MRCOOL 48,000 BTU Olympus ductless heat pump system comes with 4 concealed duct air handlers to install in your building. The three 12,000 BTU air handlers can serve a space 450 to 550 square feet each and the 18,000 BTU can serve 700 to 1000 square feet. MRCOOL packages also make installations as easy as possible, providing you with products you need for every installation. This system conveniently includes 4 wired controllers, 4 air handlers and a precharged heat pump condenser. MRCOOL provides a large variety of heat pump solutions for any occasion, so you can choose the perfect system for your home or business needs.

Get rid of all the problems of a ducted system, and rely on the flexibility and efficiency of a MRCOOL Olympus. This quad-zone ductless heat pump split system can cover larger spaces with an 18k concealed duct-style air handler and three 12k concealed duct air handlers. The system is anchored by a MULTI5-48HP230V1 condenser with 54k BTU capacity and rated a 22.4 SEER.

Warranty Terms

For a full description of all warranties applicable to this product as well as individual manufacturer requirements, please review the manufacturer's consumer brochure and/or product warranty documents.  Online warranty registration must be completed within 60 days of installation.  Due to state laws, online registration is not required in California or Quebec. Call for warranty availability on scratch & dent and surplus items.

For additional warranty information, click here.

Specifications

Model MULTI5-48HP230V1,DUCT-12HP-230,DUCT-12HP-230,DUCT-12HP-230,DUCT-18HP-230
UPC 856536005862
AHRI Number 8977710
Bundle Avg Coverage Area 2,000 - 2,400 Sq Ft
Bundle Cooling Capacity 4 Ton
Bundle Cooling Efficiency 19 SEER and Above
EER 12.5
Heat Pump Efficiency (HSPF) 10.2
Series Olympus
Zones 4
Region Compatibility Nationwide
Popular Applications Apartment, Duplex, Hotel Room, Office, Single Family Home
California Residents see Prop 65 WARNING

MULTI5-48HP230V1 Specifications:

Model MULTI5-48HP230V1
UPC 856536005862
Avg Coverage Area 2,000 - 2,400 Sq Ft
Compressor Inverter
Cooling Capacity 4 Ton
Electrical Phase 1-Phase
Heat Pump Efficiency (HSPF) 10.2
Line Set Connection Type Flared
Liquid Line Size 1/4 inch
Max Overcurrent Protection 50 amps
Primary Heating Capacity 45,001 - 50,000 BTU
Product Height (in) 52
Product Length (in) 16
Product Width (in) 37
Cooling Efficiency 19 SEER and Above
Series Olympus
System Application Type Ductless Split Systems
Voltage 240
Warranty 5 Year Parts, 7 Year Compressor
Weight (lbs) 224.0000
Region Compatibility Nationwide

DUCT-12HP-230 Specifications:

Model DUCT-12HP-230
UPC 853962006524
Air Flow Direction Horizontal
Configuration Ceiling Mounted
Blower Motor Variable Speed
Cooling Capacity 1 Ton
Electrical Phase 1-Phase
Heat Strip Compatibility NA
Line Set Connection Type Flared
Liquid Line Size 1/4 inch
Max Overcurrent Protection 15 amps
Product Height (in) 8
Product Length (in) 25
Product Width (in) 28
Series Olympus
Suction Line Size 1/2 inch
System Application Type Ductless Split Systems
Voltage 240
Warranty 5 Year Parts
Weight (lbs) 40.0000

DUCT-18HP-230 Specifications:

Model DUCT-18HP-230
UPC 853962006531
Air Flow Direction Horizontal
Configuration Ceiling Mounted
Blower Motor Variable Speed
Cooling Capacity 1.5 Ton
Electrical Phase 1-Phase
Heat Strip Compatibility NA
Line Set Connection Type Flared
Liquid Line Size 1/4 inch
Max Overcurrent Protection 15 amps
Product Height (in) 8
Product Length (in) 25
Product Width (in) 36
Series Olympus
Suction Line Size 1/2 inch
System Application Type Ductless Split Systems
Voltage 240
Warranty 5 Year Parts
Weight (lbs) 51.0000
